Industrial
NB12
The medium-payload workhorse, and the only platform in its class rated IP67 over the whole body rather than body-and-wrist separately. Three standard variants trade payload against reach.
Applications
- Handling
- Machine tending
- Grinding
- Assembly
- Inspection
- Sorting
Typical industries
PCB · Photovoltaic · Automotive parts · General manufacturing
Specifications
| Payload | 10–16 kg |
|---|---|
| Reach | 1,102–1,602 mm |
| Repeatability | ±0.03 mm |
| Axes | 6 |
| Protection | IP67 |
| Mass | 112–117 kg |
Variants
Model codes read NB<class>–<payload>/<reach in meters>. A dash in the reach column means only the nominal metre class is documented; ask us for the exact figure rather than reading it off the code.
| Designation | Payload | Reach |
|---|---|---|
| NB12-16/1.1 | 16 kg | 1,102 mm |
| NB12-12/1.4 | 12 kg | — |
| NB12-10/1.6 | 10 kg | 1,602 mm |
| NB12-15/1.4Extended variant | 15 kg | — |
Request a quotation
We quote in writing and do not publish prices. Tell us the application and we will come back with a configuration and a number.
Request a quoteFigures are ROKAE’s published specifications at nominal conditions. Achievable payload, reach and cycle time in a given cell depend on tooling, mounting, duty cycle and program. Confirm against the current datasheet and an application review before committing a design.
